Product Overview and Specifications
27
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Compatibility Note: DXLink Transmitters and Receivers are compatible with other DXLink products
(see the Compatible AMX Products listed in the table above). The Wallplate TX and the Decor
Wallplate TX require an approved DXLink power injector (see table above) when connecting directly
to an HDMI RX (Transmitters require firmware v1.2.40 or above; Receivers require firmware v1.0.80
or above). AMX does not support the use of power supplies other than the one provided or power
injectors other than those listed as they may potentially damage DXLink equipment.
AMX reserves the right to modify its products and their specifications without notice.
General Specifications (continued)
Other AMX Equipment
AMX Products Compatible with
All DXLink Transmitters
• DXLink HDMI RX
• Enova DGX Digital Media Switchers
• Enova DVX-3155HD
• Enova DVX-2155HD
AMX Products Compatible with
DXLink RX
• DXLink HDMI TX
• DXLink Multi-Format TX
• DXLink Wallplate TX
• DXLink Decor Wallplate TX
• Enova DGX Digital Media Switchers
• Enova DVX-3155HD
• Enova DVX-3150HD
• Enova DVX-2155HD
• Enova DVX-2150HD
Included Accessories Desktop power supply (ENERGY STAR
®
qualified): 1 per module
Important: Only
the provided desktop power supply should be
used, and it must not
be altered in any way.
Compatible / Optional Equipment • CC-NIRC NetLinx Emitter Cable (FG10-000-11)
• IR03 External IR Receiver Module (FG-IR03)
• PDXL-2 (FG1090-170)
• PS-POE-AT-TC (FG423-84)
NetLinx and Control Specifications
ICS LAN / Ethernet Port
(Modules Only)
• TCP/IP port (ICS LAN 10/100)
•RJ-45
Serial (Modules Only) • Bidirectional RS-232
• Standard NetLinx baud rate 1200 to 115K
• Parity support: Odd/Even/None
• 3.5 mm pluggable Phoenix terminal block
IR Control (Modules Only) • Port for use with IR03 Receiver (optional accessory FG-IR03)
• Port for use with CC-NIRC Emitter (optional accessory FG10-000-11)
USB (HID)
This port will be supported with a
future firmware upgrade.
• Multi-Format TX or HDMI TX: USB type B connector
• Wallplate TX and Decor Wallplate TX: USB mini-B connector
• Receiver Module USB type A connector
Advanced Configuration Interface USB mini-B connector (Program port)
ID Pushbutton • Toggle between DHCP and static IP addressing
• Places system in NetLinx Device ID assignment mode
• Reset the factory default settings
• Restore the factory firmware image
