Product Overview and Specifications

Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver

^ Only supported when the DXLink RX scaler is in Bypass mode and the format is 1080p60 or less.

^^ Input signal support for YCbCr 4:4:4 and 4:2:2; output color-space is converted to RGB 4:4:4.

* Dolby Digital and DTS support up to 48 kHz, 5.1 channels.

Note: Interlaced and progressive video are supported into the Transmitter; progressive is only

supported out of the Receiver unless in non-scaling Bypass mode.

AMX reserves the right to modify its products and their specifications without notice.

HDMI Video Specifications

Compatible Formats HDMI, HDCP, DVI (DVI requires conversion cable)

Signal Type Support HDMI, DVI-D (Single Link with a DVI-to-HDMI cable adapter),

DisplayPort++ (input only with HDMI cable adapter)

Video Data Rate (max.) 4.95 Gbps / 6.75 Gbps^

Video Pixel Clock (max.) 165 MHz / 225 MHz^

Progressive Resolution Support 480p up to 1920x1200 @ 60 Hz (including but not limited to those

resolutions listed on page 136 and page 139)

Interlaced Resolution Support 480i, 576i, 1080i (including but not limited to those resolutions listed on

page 136 and page 139)

Deep Color Support 24 bit, 30 bit^, 36 bit^

Color Space Support RGB 4:4:4

YCbCr^^ 4:4:4 and 4:2:2

3D Format Support Yes^ (HDMI Primary Formats)

• Frame Packing 1080p up to 24 Hz

• Frame Packing 720p up to 50/60 Hz

• Frame Packing 1080i up to 50/60 Hz

• Top-Bottom 1080p up to 24 Hz

• Top-Bottom 720p up to 50/60 Hz

• Side-by-Side Half 1080p up to 50/60 Hz

• Side-by-Side Half 720p up to 50/60 Hz

Audio Format Support Dolby TrueHD, Dolby Digital*, DTS-HD Master Audio, DTS*,

2 CH L-PCM, 6 CH L-PCM, 8 CH L-PCM
