ADV7511W HARDWARE USER’S GUIDE
Rev. A
Page 21
of 45
Rev A
Table 5
Normal RGB or YCbCr 4:4:4 (24 bits) with Separate Syncs; Input ID = 0
Input
Format
Data<23:0>
23 22 21 2019 18 17 16151413121110987 6 5 43210
RGB 444 R[7:0] G[7:0] B[7:0]
YCbCr 444 Cr[7:0] Y[7:0] Cb[7:0]
An input format of RGB 4:4:4 or YCbCr 4:4:4 can be selected by setting the input ID (
R
0x15[3:0]) to 0. There is no need to set
the Input Style (R0x16[3:2]).
