ADV7511W HARDWARE USER’S GUIDE
Rev. A
Page 19
of 45
Rev A
5.1
Mechanical Drawings and Outline Dimensions
Figure 6 64-lead Low-Profile Quad Flat Pack [LQFP-SW64-2]
COMPLIANT TO JEDEC STANDARDS MS-026-BCD-HD
1
16
17
32 32
49
64
48
33
12.20
12.00 SQ
11.80
10.20
10.00 SQ
9.80
1
16
17
49 64
48
33
PIN 1
TOP VIEW
(PINS DOWN)
BOTTOM VIEW
(PINS UP)
EXPOSED
PAD
03-16-2010-A
VIEW A
1.60
MAX
SEATING
PLANE
0.75
0.60
0.45
1.00 REF
0.15
0.05
0.08
COPLANARITY
7°
0°
0.20
0.09
VIEW A
ROTATED 90° CCW
1.45
1.40
1.35
0.27
0.22
0.17
0.50
LEAD PITCH
7.50
REF SQ
5.10
5.00 SQ
4.90
