ADV7511W HARDWARE USER’S GUIDE
Rev. A
Page 29
of 45
Rev A
Figure 11
I2S Standard Audio – 16-bit samples only
Figure 12 Serial Audio – Right-Justified
Figure 13 Serial Audio – Left-Justified
LRCLK
SCLK
I2S[3:0]
LEFT RIGHT
LSB
left
MSB
left
MSB
right
LSB
16 Clock Slots 16 Clock Slots
LSB
right
I2S Standard 16-bit per
channel
R0x0C[1:0] = ‘00’
LRCLK
SCLK
I2S[3:0]
LEFT RIGHT
LSB
MSB MSB LSB
32 Clock Slots 32 Clock Slots
MSB MSB MSB MSB
MSB-1
MSB extended
MSB extended
Serial Audio
Right Justified
R0x0C[1:0] = ‘01’
MSB-1
MSB
MSB
LRCLK
SCLK
I2S[3:0]
LEFT RIGHT
LSB
MSB MSB LSB
32 Clock Slots 32 Clock Slots
Serial Audio
Left Justified
R0x0C[1:0] = ‘10’
