ADV7511W HARDWARE USER’S GUIDE
Rev.A
Page 8
of 45
Rev A
1.2
Overview
The ADV7511W is a high speed High Definition Multimedia Interface (HDMI) transmitter that is capable of
supporting an input data rate up to 165MHz (1080p @ 60Hz, UXGA @ 60Hz). Careful hardware design (schematics
and PCB layout) is recommended to optimize the performance and to ensure HDMI compliance.
▷ The ADV7511W Programming Guide and ADV7511W Software Driver User Guide are also available if required.
1.3
Hardware Features
■ HDMI v1.4 features supported
3D video
Advanced Colorimetry
• sYCC601
• Adobe RGB
• Adobe YCC601
■ Operation up to 165MHz (TMDS link frequency)
■ Integrated CEC support with 3 message buffers
■ Supports x.v.Color™ (Gamut Metadata)
■ Internal HDCP key storage
■ Interrupt (INT) output pin eliminates constant I2C monitoring
■ Supports I2S, S/PDIF and HBR audio input formats
■ No audio Master Clock (MCLK) required for audio
■ Requires 1.8V and 3.3V supply
■ EDID buffered on chip
■ Color Space Converter (CSC) with video range clipping
■ 64-lead LQFP package
■ -40°C to +105°C temperature range
1.4
Supported Input Formats
■ 24 bit RGB 4:4:4 (separate syncs)
■ 24 bit YCbCr 4:4:4 (separate syncs)
■ 24, 20, or 16 bit YCbCr 4:2:2 (embedded or separate syncs)
■ 12, 10, or 8 bit YCbCr 4:2:2 (2x pixel clock with embedded or separate syncs)
■ 12, 10, or 8 bit YCbCr 4:2:2 (DDR with embedded or separate syncs)
1.5
Supported Output Formats
■ 24 bit RGB 4:4:4
■ 24 bit YCbCr 4:4:4
■ 24 bit YCbCr 4:2:2
