ADV7511W HARDWARE USER’S GUIDE
Rev.A
Page 22
of 45
Rev A
Table 6
YCbCr 4:2:2 Formats (24, 20, or 16 bits) Input Data Mapping:
0x48[4:3]=‘00’ (evenly distributed) Input ID=1 or 2
Input
Format
Data<23:0>
23 22 21 20 19 18 17 16151413121110987 6 5 4 3210
Style 1
YCbCr422
Sep. Sync
(24 bit)
Cb[11:4] Y[11:4] Cb[3:0] Y[3:0]
Cr[11:4] Y[11:4] Cr[3:0] Y[3:0]
YCbCr422
Sep. Sync
(20 bit)
Cb[9:2] Y[9:2] Cb[1:0]
Y[1:0]
Cr[9:2] Y[9:2] Cr[1:0] Y[1:0]
YCbCr422
Sep. Sync
(16 bit)
Cb[7:0] Y[7:0]
Cr[7:0] Y[7:0]
Style 2
24 bit Cb[11:0] Y[11:0]
Cr[11:0] Y[11:0]
20 bit Cb[9:0] Y[9:0]
Cr[9:0] Y[9:0]
16 bit Cb[7:0] Y[7:0]
Cr[7:0] Y[7:0]
Style 3
24 bit Y[11:0] Cb[11:0]
Y[11:0] Cr[11:0]
20 bit Y[9:0] Cb[9:0]
Y[9:0] Cr[9:0]
16 bit Y[7:0] Cb[7:0]
Y[7:0] Cr[7:0]
Input ID = 1: An input with YCbCr 4:2:2 with separate syncs can be selected by setting the Input ID (R0x15[3:0]) to 0x1. The
data bit width (24, 20, or 16 bits) must be set with R0x16 [5:4]. The three input pin assignment styles are shown in the table. The
Input Style can be set in R0x16[3:2].
Input ID = 2: An input with YCbCr 4:2:2 with embedded syncs (SAV and EAV) can be selected by setting the Input ID
(R0x15[3:0]) to 0x2. The data bit width (24 = 12 bits, 20 = 10 bits, or 16 = 8 bits) must be set with R0x16 [5:4]. The three input pin
assignment styles are shown in the table. The Input Style can be set in R0x16[3:2]. The only difference between Input ID 1 and
Input ID 2 is that the syncs on ID 2 are embedded in the data much like an ITU 656 style bus running at 1X clock and double
width.
