Andover Controls Infinity User Manual

Example System Points
B-2 Infinity Smoke Control Guide
TOC
Table B-1.
CX9200
Points
NAME TYPE DESCRIPTION
AH1EADmp.Cls Numeric AHU1 Exhaust Air Damper “CLOSED” LED on FSCS
AH1EADmp.Fail Numeric AHU1 Exhaust Air Damper “FAIL” LED on FSCS
AH1EADmp.Opn Numeric AHU1 Exhaust Air Damper “OPEN” LED on FSCS
AH1EADmp.OVR.Cls Numeric AHU1 Exhaust Air Damper “CLOSE” Override Switch on
FSCS
AH1EADmp.OVR.Opn Numeric AHU1 Exhaust Air Damper “OPEN” Override Switch on
FSCS
AH1OADmp.Cls Numeric AHU1 Outside Air Damper “CLOSED” LED on FSCS
AH1OADmp.Fail Numeric AHU1 Outside Air Damper “FAIL” LED on FSCS
AH1OADmp.Opn Numeric AHU1 Outside Air Damper “OPEN” LED on FSCS
AH1OADmp.OVR.Cls Numeric AHU1 Outside Air Damper “CLOSE” Override Switch on
FSCS
AH1OADmp.OVR.Opn Numeric AHU1 Outside Air Damper “OPEN” Override Switch on
FSCS
AH1RADmp.Cls Numeric AHU1 Return Air Damper “CLOSED” LED on FSCS
AH1RADmp.Fail Numeric AHU1 Return Air Damper “FAIL” LED on FSCS
AH1RADmp.Opn Numeric AHU1 Return Air Damper “OPEN” LED on FSCS
AH1RADmp.OVR.Cls Numeric AHU1 Return Air Damper “CLOSE” Override Switch on
FSCS
AH1RADmp.OVR.Opn Numeric AHU1 Return Air Damper “OPEN” Override Switch on
FSCS
AH1Rfan.Fail Numeric AHU1 Return Fan “FAIL” LED on FSCS
AH1Rfan.On Numeric AHU1 Return Fan “STATUS” LED on FSCS
AH1Rfan.OVR.Off Numeric AHU1 Return Fan “OFF” Override Switch on FSCS
AH1Rfan.OVR.On Numeric AHU1 Return Fan “ON” Override Switch on FSCS
AH1Sfan.Fail Numeric AHU1 Supply Fan “FAIL” LED on FSCS
AH1Sfan.On Numeric AHU1 Supply Fan “STATUS” LED on FSCS
AH1Sfan.OVR.Off Numeric AHU1 Supply Fan “OFF” Override Switch on FSCS
AH1Sfan.OVR.On Numeric AHU1 Supply Fan “ON” Override Switch on FSCS
AH2EADmp.Cls Numeric AHU2 Exhaust Air Damper “CLOSED” LED on FSCS
AH2EADmp.Fail Numeric AHU2 Exhaust Air Damper “FAIL” LED on FSCS
AH2EADmp.Opn Numeric AHU2 Exhaust Air Damper “OPEN” LED on FSCS
AH2EADmp.OVR.Cls Numeric AHU2 Exhaust Air Damper “CLOSE” Override Switch on
FSCS
AH2EADmp.OVR.Opn Numeric AHU2 Exhaust Air Damper “OPEN” Override Switch on
FSCS
AH2OADmp.Cls Numeric AHU2 Outside Air Damper “CLOSED” LED on FSCS
AH2OADmp.Fail Numeric AHU2 Outside Air Damper “FAIL” LED on FSCS
