Andover Controls Infinity User Manual

Configuring the System
Andover Controls Corporation 4-15
TOC
Figure 4-9. Example Point Window
Creating a Numeric Point
A Numeric Point is a variable that can be used by the Infinity system. A
Numeric Point is created the same way as an Input or Output point.
When you call up the Point window, set the Type to Numeric. A
Numeric Point does not have selections for Channel Number or
Electrical Type because they do not apply. You can select the
DETAILS box in order to enter a description for the point.
Creating an Xdriver Point
An Xdriver Point is a variable that will be used by the CX9200 to get
alarm and status information from the Fire Panel. In order to create an
Xdriver Point, create a Numeric Point and select the DETAILS1 box.
A window will appear on the screen prompting you to enter a Port. Enter
COMM4 for the Port because that is the Port that the Fire Panel is
connected to. Press the TAB key (not ENTER) after typing in COMM4
and some additional fields will appear on the screen. The number of
fields and the name of the fields will be different for different Xdrivers.
These fields correspond to the physical Fire Panel sensor numbers that
iewV ditE onnectC ogoutL
Command Window - INFINITY1
(X) Output
( ) Numeric
( ) DateTime
( ) Input
Name
Sfan
Type
SAVE
SAVE AS
Point - INFINITY1 AHU1 Sfan
(X) Digital
( ) Current
( ) TriState
( ) Pneumatic
( ) ReaderDoor
( ) Voltage
Electrical Type
(X) Enabled
( ) Disabled
State
=
( ) HiResVoltage
( ) HiResCurrent
CANCEL
DETAILS
Channel Number
1
