Smoke Control Programs
5-4 Infinity Smoke Control Guide
TOC
CX9200 Programs
The CX9200 is the central controller in the smoke control system. It
controls the communications with the Infinet controllers, the FSCS, and
the Fire Panel. The CX9200 is also responsible for initiating a smoke
control strategy, verifying that the system components are functioning
properly, and performing a weekly self-test on the dedicated smoke
control equipment.
Table 5-1 lists the programs, functions, and data files that the CX9200
uses to control the example system. :
Table 5-1. CX9200 Files
NAME TYPE DESCRIPTION
PilotLights Function Updates the FSCS LED and Override
numerics in the
CX9200 with the Infinet
controller point values.
LampPointMap Data Maps the
CX9200 numerics to the LED
numbers on the FSCS.
OutputLampString Function Formats the string that is sent to the
FSCS in order to update the LEDs.
DecodeSwitches Function Uses the string that was read from the
FSCS for the override switches and sets
the corresponding
CX9200 numerics.
FSCS_Interface Program Controls the RS-232 interface between
the
CX9200 and the FSCS.
NetStatus Function Checks the Comm status of the Infinet
controllers.
PlantFaultCheck Function Determines whether or not the fans and
dampers have reached their desired
state within the time allowed by NFPA
92A.
HornControl Program Controls the state of the FSCS audible
annunciator.
ClearFaults Program Clears all faults when the FSCS
“MASTER KEY” is ON and the “CLEAR
FAULTS” pushbutton is pressed.
FireAlarmCheck Function Determines whether or not, and in which
zones, to perform smoke control. Sets
the FSCS Alarm LEDs based on the
inputs from the Fire Panel.
SmokeSelfTest Program Runs a weekly self-test on the dedicated
controllers.
