Andover Controls Infinity User Manual

Infinity Smoke Control System Components
Andover Controls Corporation 2-9
TOC
EnergyLink 2500
The EnergyLink 2500 is an active network hub for the EnergyNet
network that has slots for plugging in various media interface modules.
The EnergyLink 2500 can perform the following functions:
• Allows the Energynet to be used in a star configuration
• Extends the length of an Energynet network
• Connects different Energynet media types together
• Allows for electrical isolation on an Energynet network by using fi-
ber optics.
Features
• Slots for up to 7 media interface modules
• Mounts inside the CX9200 cabinet
• Power (+5V DC) supplied by the CX9200 power supply
Table 2-3 lists the 3 different media interface modules that are available
for the EnergyLink 2500.
Table 2-3. EnergyLink 2500 Media Interface Modules
Media Type Media Interface Module
Twisted Pair (10BASE-T) ENL2501
Thin Coaxial (10BASE-2) ENL2502
Fiber Optic (10BASE-FL) ENL2503
