Andover Controls Infinity User Manual

Configuring the System
Andover Controls Corporation 4-19
TOC
Figure 4-12. The File Window
After entering the information into the File window, TAB to the SAVE
box and hit the ENTER key. The CX9200 will now bring up the Editor
window. The Editor window allows you to create a new Program or edit
an existing Program.
When you are editing a File, the File Menu Bar is at the top of the screen.
The File Menu Bar has pulldown menus that allow you to use the Editor.
Hit the F4 key to toggle between the Editor window and the File Menu
Bar.
When you are finished editing your program, select the File pulldown
menu from the File Menu Bar, then select the Save option. The CX9200
will now compile and save your program. The compiler will alert you if
there are any errors in the program.
If you configured the Program for AutoStart, it will begin to run after it
is compiled and saved. If not, you can Start or Stop the Program from
the Command window, or from another Program.
To exit the Editor and return to the Command window, select File Quit
from the File Menu Bar.
iewV ditE onnectC ogoutL
Command Window - INFINITY1
( ) Function
( ) Data
( ) Report
(X) Program
Filename
SmokeSelfTest
Type
SAVE
CANCEL
File - INFINITY1 SmokeSelfTest
(X) Enabled
( ) Disabled
State
Description
DELETE
DETAILS
Weekly Dedicated System Tests
(X) FallThru
( ) Looping
FlowType
(X) Command Line
( ) AutoStart
