Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 DESCRIPTION Kap.3 , Seite 10 of 18
GRZ-2698568-v1-Description.FM
3.4 Degasser/ Control cabinet
Fig. 3-12 Control box
Flow meter
Degassing chamber
Flow meter
Differential pressure transmitter;
measuring position:
Suction branch
Flow meter
Differential pressure
transmitter; measuring
position:
Flow meter
Mechanical seal
Differential pressure
transmitter
Fig. 3-13 Degassing pipe connections
Connection for differential
pressure transmitter
Flushing water connection
