Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 DESCRIPTION Kap.3 , Seite 9 of 18
GRZ-2698568-v1-Description.FM
Function: Interface between stationary and rotating parts. Absorption of
axial and radial forces.
Design:
Impeller sideCylinder roller bearing (322) with plastic cage (steel cage
optional),
Drive side Two angular contact ball bearings (321) with plastic cage (steel
cage optional).
Front wear lining Function: Protection against wear to the spiral casing (102) to prevent
contact with the impeller.
Design: Front wear lining material: 1.4460, 1.4469
Foundation frame Function: Holding the medium-consistency pump and the motor.
Design: Welded steel frame.
For detailed information on the design of the medium-consistency
pump, see:
• Principal section
• Parts list
