Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 DESCRIPTION Kap.3 , Seite 8 of 18
GRZ-2698568-v1-Description.FM
Fig. 3-11 Oil lubrication
Item Component Item Component
350
Bearing housing
421
Rotary shaft seal (421.1, 421.2)
211
Shaft
672
Vent screw
321
Roller bearing
642
Oil level indicator
322
Cylindrical roller bearing
Tab. 3-3 Main components for the bearing support
672
642
