Andritz MC - Page 66

Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 START-UP Kap.5 , Seite 6 of 8
GRZ-2698571-v1-Startup.FM
Abb. 5-1 Flowsheet showing functionality of the differential pressure transmitter
Abb. 5-2 Control of the degassing line
Measurem. pt.
1
Measurem. pt.
2
Diff. press. transm.
Contr.
valve
Signal to
control the
degassing
valve
Measurement
position 1
Measurement
position 2
Degassed pulp
Pulp in
