Distance
Sub-Menu 2
Provides for setting waveguide loss and cutoff fre-
quency of the waveguide. Selected values may be
changed using the keypad or Up/Down Arrow key.
Chosing MORE causes the soft keys, below, to be
displayed and the corresponding values to be shown
in the message area.
q
LOSS — Opens the Waveguide Loss parameter
for data entry. Enter the loss per foot (or meter)
for the type of waveguide being tested. Press
ENTER when data entry is complete. (Range is
0.000 to 5.000 dB/m)
q CUTOFF — Opens the Cutoff Frequency pa-
rameter for data entry. Enter the cutoff frequency
for the type of waveguide being tested. Press EN-
TER when data entry is complete.
q WAVE G — Opens a menu of common
waveguides. Use the Up/Down Arrow key and
ENTER key to make a selection. This feature is
provided as a rapid means of setting both
waveguide loss and cutoff frequency.
q
WINDW — Opens a menu of FFT windowing
types for DTF calculation. Use the Up/Down Ar-
row key and ENTER key to make a selection.
q
MAIN — Returns to the Main Menu.
2-17
Chapter 2 Operation
