Anritsu Site Master - Waveguide and Adapter Specifications

A-2
Appendix A Reference Data
1
8
Offset Short
3
8
Offset Short Precision Load Tunable Load Flange Type
23UM40 24UM40 26UM40 26UM40T UnivM-229
23UM48 24UM48 26UM48 26UM48T UnivM-187
23UM58 24UM58 26UM58 26UM58T UnivM-159
23UM70 24UM70 26UM70 26UM70T UnivM-137
23UM84 24UM84 26UM84 26UM84T UnivM-112
23UM100 24UM100 26UM100 26UM100T UnivM-90
23UM120 24UM120 26UM120 26UM120T UnivM-75
23UM140 24UM140 26UM140 26UM140T UnivM-62
23UM220 24UM220 26UM220 26UM220T UnivM-42
23UA229 24UA229 26UA229 26UA229T UnivUS-229
23UA187 24UA187 26UA187 26UA187T UnivUS-187
23UA159 24UA159 26UA159 26UA159T UnivUS-159
23UA137 24UA137 26UA137 26UA137T UnivUS-137
23UA112 24UA112 26UA112 26UA112T UnivUS-112
23UA90 24UA90 26UA90 26UA90T UnivUS-90
23UA75 24UA75 26UA75 26UA75T UnivUS-75
23UA62 24UA62 26UA62 26UA62T UnivUS-62
23UA42 24UA42 26UA42 26UA42T UnivUS-42
23CMR229 24CMR229 26CMR229 26CMR229T CMR229
23CMR187 24CMR187 26CMR187 26CMR187T CMR187
23CMR159 24CMR159 26CMR159 26CMR159T CMR159
23CMR137 24CMR137 26CMR137 26CMR137T CMR137
23CMR112 24CMR112 26CMR112 26CMR112T CMR112
23CMR90 24CMR90 26CMR90 26CMR90T CMR90
23UER40 24UER40 26UER40 26UER40T UER40
23UER48 24UER48 26UER48 26UER48T UER48
23UER58 24UER58 26UER58 26UER58T UER58
23UER70 24UER70 26UER70 26UER70T UER70
23UER84 24UER84 26UER84 26UER84T UER84
23UER100 24UER100 26UER100 26UER100T UER100
Table A-1. Universal Waveguide Calibration Component Part Numbers
