A-3
Appendix A Reference Data
Coaxial
Adapter
P/N
Start
Frequency
(GHz)
Stop
Frequency
(GHz)
Flange Type
Coaxial
Connector
Waveguide
Type
35UM40N 3.300 4.900 UnivM-229 Nm
WR229
WG11A
35UM48N 3.950 5.850 UnivM-187 Nm
WR187
WG12
35UM58N 4.900 7.050 UnivM-159 Nm
WR159
WG13
35UM70N 5.850 8.200 UnivM-137 Nm
WR137
WG14
35UM84N 7.050 10.000 UnivM-112 Nm
WR112
WG15
35UM100N 8.200 12.400 UnivM-90 Nm
WR90
WG16
35UM120N 10.000 15.000 UnivM-75 Nm
WR75
WG17
35UM140N 12.400 18.000 UnivM-62 Nm
WR62
WG18
35UM220K 17.000 26.500 UnivM-42 Km
WR42
WG20
35UA229N 3.300 4.900 UnivUS-229 Nm
WR229
WG11A
35UA187N 3.950 5.850 UnivUS-187 Nm
WR187
WG12
35UA159N 4.900 7.050 UnivUS-159 Nm
WR159
WG13
35UA137N 5.850 8.200 UnivUS-137 Nm
WR137
WG14
35UA112N 7.050 10.000 UnivUS-112 Nm
WR112
WG15
35UA90N 8.200 12.400 UnivUS-90 Nm
WR90
WG16
35UA75N 10.000 15.000 UnivUS-75 Nm
WR75
WG17
35UA62N 12.400 18.000 UnivUS-62 Nm
WR62
WG18
35UA42K 17.000 26.500 UnivUS-42 Km
WR42
WG20
35CMR229N 3.300 4.900 CMR229 Nm
WR229
WG11A
35CMR187N 3.950 5.850 CMR187 Nm
WR187
WG12
35CMR159N 4.900 7.050 CMR159 Nm
WR159
WG13
Table A-2. Coaxial to Universal Waveguide Adapters (1 of 2)
