Anritsu Site Master - Page 94

A-6
Appendix A Reference Data
Calibration
Component
P/N
Start
Frequency
(GHz)
Stop
Frequency
(GHz)
Waveguide
Type
Flange
Type
Compatible
Flanges
xxUA159 4.900 7.050
WR159
WG13
UnivUS-159
CPR159F
CPR159G
UG-1354/U
UG-1355/U
UG-1730/U
UG-1731/U
xxUA137 5.850 8.200
WR137
WG14
UnivUS-137
CPR137F
CPR137G
UG-1356/U
UG-1357/U
UG-1732/U
UG-1733/U
UG-343B/U
UG-344/U
UG-440B/U
UG-441/U
xxUA112 7.050 10.00
WR112
WG15
UnivUS-112
CPR112F
CPR112G
UG-1358/U
UG-1359/U
UG-1734/U
UG-1735/U
UG-52B/U
UG-51/U
UG-137B/U
UG-138/U
xxUA90 8.200 12.400
WR90
WG16
UnivUS-90
CPR90F
CPR90G
UG-1360/U
UG-1361/U
UG-1736/U
UG-1737/U
UG-40B/U
UG-39/U
UG-135/U
UG-136B/U
xxUA75 10.000 15.000
WR75
WG17
UnivUS-75 WR75
xxUA62 12.400 18.000
WR62
WG18
UnivUS-62
UG-541A/U
UG-419/U
UG-1665/U
UG-1666/U
xxUA42 17.000 26.500
WR42
WG20
UnivUS-42
UG-596A/U
UG-595/U
UG-597/U
UG-598A/U
xxCMR229 3.300 4.900
WR229
WG11A
CMR229 CMR229
xxCMR187 3.950 5.850
WR187
WG12
CMR187
CMR187
UG-1475/U
UG-1480/U
Table A-3. Universal Flange Compatibility (2 of 3)
