Anritsu Site Master - Page 95

A-7
Appendix A Reference Data
Calibration
Component
P/N
Start
Frequency
(GHz)
Stop
Frequency
(GHz)
Waveguide
Type
Flange
Type
Compatible
Flanges
xxCMR159 4.900 7.050
WR159
WG13
CMR159 CMR159
xxCMR137 5.850 8.200
WR137
WG14
CMR137
CMR137
UG-1476/U
UG-1481/U
xxCMR112 7.050 10.000
WR112
WG15
CMR112
CMR112
UG-1477/U
UG-1482/U
xxCMR90 8.200 12.400
WR90
WG16
CMR90
CMR90
UG-1478/U
UG-1483/U
xxUER40 3.300 4.900
WR229
WG11A
UER40 UER40
xxUER48 3.950 5.850
WR187
WG12
UER48 UER48
xxUER58 4.900 7.050
WR159
WG13
UER58 UER58
xxUER70 5.850 8.200
WR137
WG14
UER70 UER70
xxUER84 7.050 10.000
WR112
WG15
UER84 UER84
xxUER100 8.200 12.400
WR90
WG16
UER100 UER100
Table A-3. Universal Flange Compatibility (3 of 3)
