A-8
Appendix A Reference Data
Offset Short P/N Frequency (GHz) Length (mm)
24UM40 4.021 36,419 ±.14
24UM48 4.807 30,979 ±.11
24UM58 5.878 24,664 ±.09
24UM70 6.926 20,710 ±.08
24UM84 8.396 17,040 ±.05
24UM100 10.084 14,675 ±.05
24UM120 12.247 11,978 ±.04
24UM140 14.940 9,742 ±.04
24UM220 21.225 7,067 ±.03
24UA229 4.021 36,419 ±.14
24UA187 4.807 30,979 ±.11
24UA159 5.878 24,664 ±.09
24UA137 6.926 20,710 ±.08
24UA112 8.396 17,040 ±.05
24UA90 10.084 14,675 ±.05
24UA75 12.247 11,978 ±.04
24UA62 14.940 9,742 ±.04
24UA42 21.225 7,067 ±.03
24CMR229 4.021 36,419 ±.14
24CMR187 4.807 30,979 ±.11
24CMR159 5.878 24,664 ±.09
24CMR137 6.926 20,710 ±.08
24CMR112 8.396 17,040 ±.05
24CMR90 10.084 14,675 ±.05
24UER40 4.021 36,419 ±.14
24UER48 4.807 30,979 ±.11
24UER58 5.878 24,664 ±.09
24 UER70 6.926 20,710 ±.08
24UER84 8.396 17,040 ±.05
24UER100 10.084 14,675 ±.05
➀
Offset Shorts are
3
8
wave at the geometric mean frequency of the waveguide band;
dimensionally accurate to <0.5 degree at the maximum operating frequency of the
corresponding waveguide.
Table A-4. Waveguide Offset Short
➀
Specifications
