Waveguide
Type/Model
Start
Frequency
(GHz)
Stop
Frequency
(GHz)
Cutoff
Frequency
(GHz)
Mid-Band Loss
(dB/ft, GHz)
Cablewave
WE37 3.600 4.200 2.830 0.0082
WE46 4.400 5.000 3.000 0.0108
WE61 5.925 6.425 3.600 0.0119
WE65 6.425 7.125 4.000 0.0138
WE70 7.125 7.750 4.300 0.0123
WE78 7.125 8.500 4.670 0.0136
WE108 10.500 11.700 6.570 0.0298
WE130 11.700 13.250 7.430 0.0348
WE150 14.000 15.350 8.600 0.0426
WE191 17.700 19.700 10.680 0.0595
Hanover
E38 3.100 4.200 2.320 0.0074, 3.6
EH46 4.400 5.000 3.080 0.0110
E54 5.000 6.000 3.870 0.0143, 5.4
E60 5.600 6.425 3.600 0.0108
E65 5.925 7.125 3.990 0.0139
E70 6.425 7.750 4.290 0.0146
EH78 7.700 8.500 4.650 0.0211, 8.2
E100 8.500 10.000 6.440 0.0271, 9.5
E105 10.700 11.700 6.600 0.0277
E130 10.950 13.250 8.400 0.0344
E150 14.000 15.350 10.490 0.0422
E185 17.300 19.700 11.100 0.0588
E220 21.200 23.600 12.900 0.0915, 22.5
Table A-5. Waveguide Technical Data (2 of 2)
