Anritsu Site Master - Coaxial Cable Technical Data

Appendix A Reference Data
Cable Type
Maximum
Frequency (GHz)
Relative Propagation
Velocity (
V
f
)
Nominal Attenuation
dB/100 ft @ 6 GHz
FSJ1-50A
20.4 0.84 16.2
FSJ2-50
13.4 0.83 11.4
FSJ4-50B
10.2 0.81 10.6
EFX2-50
13.5 0.85 10.4
LDF1-50
15.8 0.86 9.34
LDF2-50
13.5 0.88 9.85
LDF4-50A
8.8 0.88 6.64
HJ4-50
10.9 0.914 7.84
HJ4.5-50
6.6 0.92 4.5
Table A-6. Coaxial Cable Technical Data
A-11/A-12
