A-2 Test Records for Spectrum Analyzer Verification Appendix A — Test Records
A-32 PN: 10580-00279 Rev. E MS272xC MM
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-59. Spectrum Analyzer Residual Spurious (Preamp Off)
Start Freq Stop Freq RBW VBW Measured Values (Marker 1) Specification
9kHz 100kHz 300Hz 10Hz dBm ≤ –90 dBm
100 kHz 10 MHz 300 Hz 100 Hz dBm ≤ –90 dBm
10 MHz 2 GHz 30 kHz 3 kHz dBm ≤ –90 dBm
2GHz 4GHz 10kHz 1kHz dBm ≤ –90 dBm
4GHz 5.35GHz 10kHz 300Hz dBm ≤ –90 dBm
5.35 GHz 7.2 GHz 3 kHz 300 Hz dBm ≤ –90 dBm
7.2GHz 8.2GHz 3kHz 300Hz dBm ≤ –90 dBm
8.2GHz 9GHz 3kHz 300Hz dBm ≤ –90 dBm
9 GHz 10 GHz 1 kHz 100 Hz dBm ≤ –90 dBm
10 GHz 11.1 GHz 300 Hz 100 Hz dBm
≤ –90 dBm
11.1 GHz 13 GHz 1 kHz 100 Hz dBm
≤ –90 dBm
13GHz 16.5GHz 1kHz 100Hz dBm
≤ –85 dBm
16.5 GHz 17.5 GHz 300 Hz 30 Hz dBm
≤ –85 dBm
17.5 GHz 18.5 GHz 300 Hz 30 Hz dBm
≤ –85 dBm
18.5GHz 19.25GHz 300Hz 30Hz dBm
≤ –85 dBm
19.25 GHz 20 GHz 300 Hz 30 Hz dBm
≤ –85 dBm
20.006 GHz 22 GHz 10 kHz 300 Hz dBm
≤ –80 dBm
22 GHz 24 GHz 10 kHz 300 Hz dBm
≤ –80 dBm
24 GHz 26 GHz 10 kHz 300 Hz dBm
≤ –80 dBm
26 GHz 28 GHz 10 kHz 300 Hz dBm
≤ –80 dBm
28 GHz 30 GHz 10 kHz 300 Hz dBm
≤ –80 dBm
30 GHz 32 GHz 10 kHz 300 Hz dBm
≤ –80 dBm
32GHz 34GHz 1kHz 300Hz dBm
≤ –80 dBm
34GHz 36GHz 1kHz 300Hz dBm
≤ –80 dBm
36GHz 38GHz 1kHz 300Hz dBm
≤ –80 dBm
38GHz 40GHz 1kHz 300Hz dBm
≤ –80 dBm
40GHz 42GHz 1kHz 300Hz dBm
≤ –80 dBm
42GHz 43GHz 1kHz 300Hz dBm
≤ –80 dBm
