Appendix A — Test Records A-2 Test Records for Spectrum Analyzer Verification
MS272xC MM PN: 10580-00279 Rev. E A-33
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-60. Spectrum Analyzer Residual Spurious (Preamp On)
Start Freq Stop Freq RBW VBW Measured Values (Marker 1) Specification
9 kHz 100 kHz 300 Hz 10 Hz dBm ≤ –100 dBm
100 kHz 10 MHz 3 kHz 300 Hz dBm ≤ –100 dBm
10MHz 2GHz 30kHz 3kHz dBm ≤ –100 dBm
2GHz 4GHz 30kHz 3kHz dBm ≤ –100 dBm
4GHz 5.35GHz 30kHz 3kHz dBm ≤ –100 dBm
5.35 GHz 7.2 GHz 30 kHz 1 kHz dBm ≤ –100 dBm
7.2GHz 9GHz 30kHz 3kHz dBm ≤ –100 dBm
9GHz 11.1GHz 10kHz 1kHz dBm ≤ –100 dBm
11.1 GHz 13 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
13 GHz 16.2 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
16.2 GHz 18 GHz 3 kHz 300 Hz dBm ≤ –100 dBm
18 GHz 18.8 GHz 10 kHz 1 kHz dBm ≤ –100 dBm
18.8 GHz 20 GHz 3 kHz 300 Hz dBm ≤ –100 dBm
20.006 GHz 22 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
22 GHz 24 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
24 GHz 26 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
26 GHz 28 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
28 GHz 30 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
30 GHz 32 GHz 30 kHz 3 kHz dBm ≤ –100 dBm
32GHz 34GHz 3kHz 300Hz dBm
≤ –95 dBm
34GHz 36GHz 3kHz 300Hz dBm
≤ –95 dBm
36GHz 38GHz 3kHz 300Hz dBm
≤ –95 dBm
38GHz 40GHz 3kHz 300Hz dBm
≤ –95 dBm
40GHz 42GHz 3kHz 300Hz dBm
≤ –95 dBm
42GHz 43GHz 3kHz 300Hz dBm
≤ –95 dBm
