A-2 Test Records for Spectrum Analyzer Verification Appendix A — Test Records
A-34 PN: 10580-00279 Rev. E MS272xC MM
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-61. Spectrum Analyzer DANL (Preamp On)
Frequency
Start / Stop
RBW
(kHz)
VBW
(kHz)
Measured dBm
(100 kHz RBW)
Calculated dBm
(1 Hz RBW)
1Hz
Specification
10 MHz to 4.0 GHz 100 1 dBm dBm ≥ –160 dBm
4.0 GHz to 9.0 GHz 100 1 dBm dBm ≥ –156 dBm
9.0 GHz to 13 GHz 100 1 dBm dBm ≥ –152 dBm
13 GHz to 20 GHz 100 1 dBm dBm ≥ –145 dBm
20 GHz to 32 GHz 100 1 dBm dBm ≥ –154 dBm
32 GHz to 40 GHz 100 1 dBm dBm ≥ –147 dBm
Table A-62. Spectrum Analyzer DANL (Preamp Off)
Frequency
Start / Stop
RBW
(kHz)
VBW
(kHz)
Measured dBm
(100 kHz RBW)
Calculated dBm
(1 Hz RBW)
1Hz
Specification
10 MHz to 4.0 GHz 100 1 dBm dBm ≥ –141 dBm
4.0 GHz to 9.0 GHz 100 1 dBm dBm ≥ –134 dBm
9.0 GHz to 13 GHz 100 1 dBm dBm ≥ –129 dBm
13 GHz to 20 GHz 100 1 dBm dBm ≥ –123 dBm
20 GHz to 32 GHz 100 1 dBm dBm ≥ –134 dBm
32 GHz to 40 GHz 100 1 dBm dBm ≥ –127 dBm
Table A-63. Spectrum Analyzer Third Order Intercept
Third Order Intercept at
Center Frequency Measured Value Specification
2400.151 MHz dBm
2399.851 MHz dBm
Calculated TOI at 2400 MHz dBm ≥ +15 dBm
