Appendix E: Anybus CompactCom 40 without Housing 102 (114)
E.7.1 General
1.6
2.3
(Host Application PCB)
44.5
36.6 32.6
6
28.6
6
R 1.2
1.8
27.4
2
R
Component-free area
Fig. 57
E.7.2 Standard LED Positions
Standard Anybus CompactCom:
23.5
34.3
2.3
0
Module
Status
Network
Status
Fig. 58
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
