Anybus CompactCom M40 User Manual

Introduction 6 (114)
2 Introduction
2.1 General Description
All Anybus CompactCom module implementations share the same footprint and electrical
interface, allowing the host application to support all major networking systems using the same
hardware platform. In the same way all Anybus CompactCom B40-1 share footprint and
electrical interface. This document describes the hardware details of the Anybus CompactCom
M40 modules, both with and without housing. Please consult the Anybus CompactCom B40–1
Design Guide for specific information about the Anybus CompactCom B40–1 brick solution.
This a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
This product contains ESD (Electrostatic Discharge) sensitive parts that may be
damaged if ESD control procedures are not followed. Static control precautions are
required when handling the product. Failure to observe this may cause damage to
the product.
2.2 Features
• Hardware support for triple buffered process data, which increases performance
• Supports synchronization for selected industrial networks
• Black channel interface, offering a transparent channel for safety communication for
selected networks
• Low latency
• Integrated protocol stack handling (where applicable)
• Galvanically isolated network interface (where applicable)
• On-board network status indications according to each network standard (where
applicable)
• On-board network connectors according to each network standard
• Compact size (52 x 50 mm, 2”″ x 1.97″”)
• Firmware upgradable (FLASH technology)
• 3.3 V design
• 8-bit and 16-bit parallel modes
• SPI mode
• Shift register mode
• Precompliance tested for network conformance (where applicable). Not finalized. All
Anybus CompactCom versions will be precertified for network conformance. While this is
done to ensure that the final product can be certified, it does not necessarily mean that the
final product does not require recertification. Contact HMS for further information.
• Precompliance tested for CE & UL. Not finalized. Contact HMS for further information.
• Version with M12 connector available for several networks.
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
