Anybus CompactCom M40 User Manual

Appendix B: Backward Compatibility 69 (114)
B.11 Network Specific — PROFIBUS
B.11.1 Additional Diagnostic Object (05h)
Object removed in the 40-series. To create diagnostics, use Diagnostic Object (02h).
Another option is to use the PROFIBUS DP-V0 Diagnostic Object (10h) where diagnostics can
be sent transparently from the host application to the network.
If you use the Additional Diagnostic Object you need to update your software implementation.
B.11.2 Network PROFIBUS DP-V1 Object (0Bh)
Object removed in the 40-series, i.e. commands Map_ADI_Specified_Write_Area and Map_
ADI_Specified_Read_Area are not supported.
B.11.3 PROFIBUS DP-V1 Object (FDh)
Attribute 30-series 40-series Change/Action/Comment
#1, PNO Ident
Number
1811h 1815h If the attribute is implemented in the host
application, it overrides the default value and
there is no difference between the 30-series
and the 40-series.
If the attribute is not implemented, the default
value is used.
#2, Parameterization
Data
See Comment In the first 10 bytes, only the Parameter Struct
bit (bit 3) is copied to this attribute in the 40-
series. All other bits are set to 0.
In the 30-series all information in the first 10
bytes were copied.
#5, Size of Identifier
Related Diagnostics
Available Removed Attribute removed in the 40-series. The
Anybus CompactCom will never request this
attribute.
Nothing needs to be changed.
#6, Buffer Mode Available Removed Attribute removed in the 40-series. The
Anybus CompactCom will never request this
attribute. No buffer modes needed in the 40-
series since maximum sizes for all buffers are
supported.
Nothing needs to be changed.
#7, Alarm Settings Available Removed Attribute removed in the 40-series. The
Anybus CompactCom will never request this
attribute. Only Diagnostic Alarms supported.
#16, I&M Version Available Removed Attribute removed in the 40-series. The
Anybus CompactCom will never request this
attribute. The host application cannot influence
the I&M version implemented by the Anybus
CompactCom.
#17, I&M Supported Available Removed Attribute removed in the 40-series. The
Anybus CompactCom will never request this
attribute. The host application cannot influence
the I&M version supported by the Anybus
CompactCom.
#19, Check Config
Behavior
Available Removed Attribute removed in the 40-series. The
Anybus CompactCom will never request this
attribute.
The 40-series depends on CheckCfgMode
(often configurable in the PROFIBUS master)
in default mode. Either the expected and actual
configuration must match exactly or can differ
as long as the expected input and output sizes
are equal or larger than the actual sizes.
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
