Anybus CompactCom M40 User Manual

Appendix D: Mechanical Specification 90 (114)
D.4.1 Front
48.6
R 3
R 2
R 0.5
20.8 22.9
1
1
6.5 33.6
0.8
1.1
50.8
Fig. 42
D.5 Slot Cover
HMS Industrial Networks AB can supply a “blind” slot-cover, which may be used to cover the
Anybus CompactCom slot when not in use, allowing the Anybus CompactCom module to be
supplied as an end-user option instead of being mounted during manufacturing.
The dimensions below are given in millimeters and include a tolerance of ±0.10 mm.
50.1
50.5
22.3 19.9 13.0
8.8
1.1
3.5
40.0
Fig. 43
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
