Anybus CompactCom M40 - Overview; D.1 Overview

Appendix D: Mechanical Specification 86 (114)
D.1 Overview
The dimensions below are given in millimeters and include a tolerance of ±0.20 mm.
0
33.7 39.6 49.2 50.7 51.8
0
1.7
3.4
1.3
18.9
8.4
18.1
42.1
48 50.1
22.3
R3
B
A
A
B
C
C
C
Grounding (GND) Mechanics
Functional Earth (FE) Mechanics
Fastening Mechanics
Fig. 36
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
