Appendix C: Technical Specification 84 (114)
C.4 Regulatory Compliance
C.4.1 EMC Compliance (CE)
Since the Anybus CompactCom is considered a component for embedded applications, it
cannot be CE-marked as an end product. However, the CompactCom family is precompliance
tested in a typical installation providing that all modules conforms to the EMC directive in that
installation.
Once the end product has successfully passed the EMC test using any of the Anybus
CompactCom modules, the precompliance test concept allows any other interface of the same
type in the Anybus CompactCom family to be embedded in that product without further EMC
tests.
To be compliant to the EMC directive 2004/108/EC, the precompliance testing has been
conducted according to the following standards:
• Emission: EN61000-6-4
EN55016-2-3 Radiated emission
EN55022 Conducted emission
• Immunity: EN61000-6-2
EN61000-4-2 Electrostatic discharge
EN61000-4-3 Radiated immunity
EN61000-4-4 Fast transients/burst
EN61000-4-5 Surge immunity
EN61000-4-6 Conducted immunity
Since all Anybus CompactCom modules have been evaluated according to the EMC directive
through the above standards, this serves as a base for our customers when certifying Anybus
CompactCom based products.
C.4.2 UL/c-UL Compliance
The certification has been documented by UL in file E214107.
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
