Appendix B: Backward Compatibility 65 (114)
B.9 Network Specific — EtherNet/IP
B.9.1 Network Object (03h)
Attribute #1, Network
Type
The 30-series module is available in two network type versions, either with “Beacon
based DLR” (Highest performance) or with “Announce based DLR” which both are
Ethernet redundancy protocols. The 40-series is only available with “Beacon based
DLR”. The network type value differs between the versions.
Value Network Type Anybus CompactCom Product
0085h EtherNet/IP, No DLR 30-series 1-port
009Ch EtherNet/IP, Announce Based DLR 30-series 2-port
009Bh EtherNet/IP, Beacon Based DLR 30-series and 40-series
00ABh EtherNet/IP, Beacon Based DLR + IIoT 40–series
B.9.2 EtherNet/IP Host Object (F8h)
Attribute Default Anybus CompactCom
Product
Comment
#2, Device
Type
0000h 30-series, EtherNet/IP, No
DLR
If the attribute is implemented in the
host application, it overrides the
default value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented, the
default value is used.
0000h 30-series, EtherNet/IP,
Announce Based DLR
002Bh 30-series, EtherNet/IP,
Beacon Based DLR
002Bh 40-series, EtherNet/IP,
Beacon Based DLR
#3, Product
Code
0063h 30-series, EtherNet/IP, No
DLR
If the attribute is implemented in the
host application, it overrides the
default value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented, the
default value is used.
002Eh 30-series, EtherNet/IP,
Announce Based DLR
0036h 30-series, EtherNet/IP,
Beacon Based DLR
0037h 40-series, EtherNet/IP,
Beacon Based DLR
#6, Product
Name
Anybus-CC EtherNet/IP 30-series, EtherNet/IP, No
DLR
If the attribute is implemented in the
host application, it overrides the
default value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented, the
default value is used.
CompactCom EtherNet/IP
(TM) 2P
30-series, EtherNet/IP,
Announce Based DLR
Anybus-CC EIP (2-Port)
BB DLR
30-series, EtherNet/IP,
Beacon Based DLR
Anybus CompactCom 40
EtherNet/IP(TM)
40-series, EtherNet/IP,
Beacon Based DLR
Attribute #27,
Producing
Instance Map
See comment Attribute removed in the 40-series
(only available in the 30-series
EtherNet/IP Beacon Based DLR). The
CompactCom will never request this
attribute. Replaced by the functionality
in the Assembly Mapping Object (EBh).
If this attribute is used, the Assembly
Mapping object must be implemented
instead.
Attribute #28,
Consuming
Instance Map
See comment Attribute removed in the 40-series
(only available in the 30-series
EtherNet/IP Beacon Based DLR). The
CompactCom will never request this
attribute. Replaced by the functionality
in the Assembly Mapping Object (EBh).
If this attribute is used, the Assembly
Mapping object must be implemented
instead.
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
