Appendix E: Anybus CompactCom 40 without Housing 110 (114)
E.8.2 IP Rating
To ensure that the final design will fulfill the requirements for IP67 rating, the M12 connectors
have to be firmly and tightly attached on both sides of the front plate. The dimensions for the
front plate are given below.
21
12
13,5
A
A
9,2
0,6
1 ≤ x ≤ 2
SECTION A-A
Fig. 69
Anybus
®
CompactCom
M40 Hardware Design Guide HMSI-216-126 EN 2.6
