Appendix B: Backward Compatibility 77 (114)
Module Status LED (LED2[A..B])
LED State 30-series 40-series Comments
Off Not Initialized Not Initialized No power or Module in SETUP or NW_
INIT state
Green Normal Operation Normal Operation Module has shifted from the NW_INIT
state
Green, 1 flash Diagnostic Event Diagnostic Event Diagnostic event(s) present
Green, cont. flash Identify
-
Flashing 1Hz continuously to identify
slave (DCP_Identify).
Red Exception error Exception error Module in state Exception
Fatal Event Fatal Event Major internal error (this indication is
combined with a red Network Status
LED)
Red, 1 flash Configuration error
-
Red, 2 flashes IP address error
-
Red, 3 flashes Station Name Error
-
Red, 4 flashes Internal error
-
Alternating Red/Green
-
Firmware Update Do NOT power off the module. Turning
the module off during this phase could
cause permanent damage.
B.12.9 SNMP MIB-II
sysContact, sysLocation and sysName are used to give the product identification in the end
installation.
In the 40-module these variables are only set from the network using SNMP protocol by the end
user.
Due to this, sysContact (PROFINET IO object (F6h), Attribute 22), sysLocation (Network
Configuration Object (04h), Attribute 17) and sysName (Network Configuration Object (04h),
Attribute 15) are no longer used.
Nothing needs to be updated in your implementation but attribute values will no longer be used.
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
