Patient monitor User’s manual
Chapter 19-12
Select
【
Primary Lead
】，
choose the ECG lead displayed on Standard
Screen or Big Numerics Screen. And this lead will also be displayed on the
12lead Screen as the primary lead.
b. Setting ECG Gain
Select【ECG Gain】, choose the appropriate gain. You can choose from
【Auto】,【×0.125】,【×0.25】,【×0.5】,【×1】,【×2】and【×4】.
c. Setting HR Limit
Select【HR Up Limit】and【HR Down Limit】, input the limit value.
d. Setting Alarm Switch
Select
【
Alarm Switch
】
, set it to
【
On
】
or
【
Off
】
.
e. Setting Alarm Level
Select【Alarm Level】, set it to【Low】or【Mid】or【High】.
f. Setting ECG Module
Select【ECG Mode 】，choose the appropriate mode. You can choose from
【USER】,【DIA】,【SUR】and【MON】.
The states of the filter under various modes of ECG:
Drift
HUM
EMG
DIA
OFF
Optional
OFF
SUR
Intense
ON
Intense
MON
Mild
ON
Mild
USER
Optional
Optional
Optional
Note: Under the mode of SUR and MON, the state of the filter
cannot be regulated. Only under the state of USER and DIA
can the state be regulated.
g. Setting Filter
When the【USER】in【ECG Mode】is selected，it is necessary to set the
filter, operations are as follows:
 Select
【
Drift
】
to choose the appropriate setup. You can choose from
【OFF】,【Mild】and【Intense】.
 Select【EMG】to choose the appropriate setup. You can choose from
【
OFF
】
,
【
Mild
】
and
【
Intense
】
.
Filter
ECG mode

