Patient monitor User’s manual
20
 Sidestream CO
2
module (CPT)
Measurement range
0.0 % to 13.1 % (0 mmHg to 99.6 mmHg)
Resolution
0.1% or 1mmHg
Unit
%, mmHg, kPa
Accuracy
0% to 4.9%，±0.3 % (±2.0 mmHg)
5.0% to 13.1%，＜±10 % of the reading
Measurement range
of awRR
3 rpm to 150 rpm
Warm up time
Reach 97% of full specifications within 45s and full
specifications within 10 minutes.
Rise time
About 100ms when using 1.5m sampling tube and adult
dehydration flask with 120ml/min flow rate.
CO
2
Response Time
<4s when using 1.5m sampling tube and adult
dehydration flask with 120ml/min flow rate.
Sample Flow Rate
User adjustable, 50ml/min, 100ml/min, 150ml/min,
200ml/min, 250ml/min
Calibration
Offset calibration, auto/ manual; gain calibration
 Mainstream CO
2
module (CAPNOSTAT5)
Warm up time
Capnogram displayed in less than 15 s, at an ambient
temperature of 25℃, full specifications within 2
minutes.
Measurement range
0% to 19.7 %（0 mmHg to 150 mmHg）
Resolution
0.1% or 1mmHg
Stability
Short term drift: ±0.8mmHg over four hours
Long term drift: Accuracy specification will be
maintained over a 120 hour period.
Rise time
＜
60ms
Unit
%, mmHg, kPa
Accuracy
0 mmHg to 40 mmHg, ±2 mmHg
41 mmHg to 70 mmHg, ±5% of reading
71 mmHg to 100 mmHg, ±8% of reading
101 mmHg to 150 mmHg, ±10% of reading
The temperature is 35℃
