Patient monitor User’s manual
19
Static pressure
measurement
accuracy
±1 mmHg or ±2% of the reading, whichever is the
greater (exclusive of transducer)
±4 mmHg or ±4% of the reading, whichever is the
greater (inclusion of transducer)
Dynamic pressure
measurement range
-50 mmHg to +350mmHg
Dynamic pressure
measurement
accuracy
±4mmHg or ±4% of the reading, whichever is the
greater
Resolution
1 mmHg
Unit
mmHg, kPa, cmH
2
O
Frequency Response
0 Hz to 20 Hz
Kinds of
Measurement
ART, PA, CVP, RAP, LAP, ICP, P1/P2
Alarm range:
ART
PA
CVP/RAP/LAP/ICP
P1/P2
0 mmHg to 350 mmHg
-10 mmHg to +120 mmHg
-10 mmHg to +40 mmHg
-50 mmHg to +350 mmHg
Zero calibration of
pressure
When IBP sensor is connected or use IBP measurement
every 4 h, need to connect the standard atmosphere
to perform zero calibration.
Range of pressure
zero calibration
±200mmHg
Accuracy of pressure
zero calibration
±1mmHg
A.6.7 CO
2
Measurement mode
Sidestream, mainstream, microstream
Measurement way
Infrared spectrum
Alarm range
0 mmHg to 152 mmHg, high/low limit can be adjusted
continuously.
