ARAG VISIO BLC - Menu Structure

13
SETTING
- Access the selected menu
- Confirm changes and go back to previous menu
- Go back to previous menu
- Quit without confirming the changes
Pressed in sequence:
- Scroll the pages of a menu
- Change a value (increase)
Move the cursor during a change (press a
few times)
PROGRAMMING KEYSPROGRAMMING KEYS
11 MENU STRUCTURE
For a correct use of the keys during setting, refer to par. 10.2.
SETUP MENU
SETTINGS
BLC settings
Basic settings
Start procedure
Number of sensors
External sens. [X]
External sens. [Y]
Internal sens. [X]
Internal sens. [Y]
HL Button
Boom settings
Boom geometry
Actuators
Boom width
Parameters adjust.
Height ctrl aggr.
Tilt. ctrl aggress.
Height error gain
Tilt. speed damping
Funct. Definition Headland detection
IBX Properties
Device name
Hardware version
Firmware version
Serial number
Activation code
OPTIONS
Language
Česky - Deutsch - English - Español - Français - Magyar
Italiano - Polski - Português - Русский
Unit of measurement
Speed
m/s
ft/s
Length
m
ft
Height
cm
in
Angle
°
rad
Display contrast
Alarm tones
Keytones
User access
Operator
Manager
Technician
ARAGTech
Operating mode
Operating mode:
Only BLC
Only TTC
BLC and TTC
Boom geometry:
Fixed
Golf sprayer
Multi-row sprayer
SETUP MANAGEMENT
Save VISIO setup
Load VISIO setup
Save IBX setup
Load IBX setup
TEST
Firmware version
Hardware version
Battery voltage
Display
Keys
Sensors
IBX UPDATE
FACTORY DEFAULT
VISIO restore
IBX restore
