3
INTRODUCTION
• MANUAL USE MODES
The section of this manual dedicated to the installation contains information for installers. For this reason we have used technical terms without
providing explanations which would be necessary for end users only.
THE INSTALLATION MUST BE CARRIED OUT BY AUTHORIZED AND SKILLED PERSONNEL ONLY. ARAG IS NOT RESPONSIBLE
FOR ANY OPERATION SPECIFIED IN THIS MANUAL CARRIED OUT BY UNAUTHORIZED OR UNSKILLED PERSONNEL.
• RESPONSIBILITY
The installer must carry out "workmanlike" installations and ensure to the end user the perfect operation of the whole system both with ARAG
components only and other brands' components.
ARAG always recommends using its components to install control systems.
The installer will be held responsible for any malfunction if he decides to use other brands' components even without actually changing the system
parts or harness.
The compatibility check with components and accessories of other manufacturers shall be carried out by the installer.
If the ARAG components installed together with other brands' components get damaged because of what stated above, no direct or indirect
warranty will be provided.
1 RISKS AND PROTECTIONS
All installation works must be done with battery disconnected, using suitable tools and any individual protection equipment
deemed necessary.
Use ONLY clean water for treatment tests and simulations: using chemicals during simulated treatment runs can seriously
injure persons in the vicinity.
DO NOT WORK NEAR THE BOOM WHILE THE BLC CONTROL SYSTEM IS IN OPERATION.
2 PRODUCT DESCRIPTION
BLC Visio is the stand alone system for boom leveling control (BLC) that allows keeping the sprayer arm parallel to the field orientation and managing
its distance from the ground through the dedicated control unit - IBX100 hydraulic control unit- so as to ensure an even spraying covering.
The IBX100 hydraulic unit supplied with the BLC kit is already active for use.
A new activation code is NECESSARY ONLY with the purchase of a spare control unit (activation procedure on page20).
3 INTENDED USE
The equipment is designed and built to work on agricultural machinery for spraying and crop spraying applications on golf
courses, in compliance with EN ISO 14982 standard (Electromagnetic compatibility - Forestry and farming machines, for green
spaces and gardens) harmonized with Directive 2014/30/EU.
4 PRECAUTIONS
• Do not aim water jets at the equipment.
• Do not use solvents or fuel to clean the case outer surface.
• Do not clean equipment with direct water jets.
• Comply with the specified power voltage (12 VDC).
• In case of voltaic arc welding, remove connectors from the device and disconnect the power cables.
• Only use ARAG genuine spare parts and accessories.
