WEB BROWSER-BASED CONFIGURATION
The number of physical drives in the SATA Raid controller deter-
mines the RAID levels that can be implemented with the raid set.
You can create a raid set associated with exactly one volume set.
The user can change the raid level, stripe size, and capacity. A hot
spare option is also created depending upon the existing congura-
tion.
Click the “Conrm The Operation” check box and click on the Sub-
mit button in the Quick Create screen, the raid set and volume set
will start to initialize.
Note:
In Quick Create, your volume set is automatically congured
based on the number of disks in your system. Use the Raid Set
Function and Volume Set Function if you prefer to customize your
system.
Note:
If volume capacity will exceed 2TB, controller will show the
Greater 2 TB volume Support sub-menu. Greater Two TB Volume
Support No, 64bit LBA and For Windows.
For more details please download PDF file from ftp://ftp.
areca.com.tw/RaidCards/Documents/Manual_Spec/
Over2TB_050721.zip
6.5 RaidSet Functions
Use the Raid Set Function and Volume Set Function if you prefer
to customize your system. Manual conguration can provide full
control of the raid set settings, but it will take longer to complete
than the Quick Volume/Raid Setup conguration. Select the Raid
Set Function to manually congure the raid set for the rst time or
delete and recongure existing raid sets. (A raid set is a group of
disks containing one or more volume sets.)
6.5.1 Create Raid Set
To create a raid set, click on the “Delete Raid Set” link. A “Select
