Areca ARC-1280ML - Board Layout

HARDWARE INSTALLATION
32
2.2 Board Layout
Follow the instructions below to install a PCI RAID Card into your
PC / Server.
Figure 2-1, ARC-1110/1120 (4/8-port PCI-X SATA RAID Controller)
Figure 2-2, ARC-1210/1220 (4/8-port PCI-Express SATA RAID Con-
troller)
