13 Operating the PGB Functional Unit
13.1 Opening the upstream and downstream earthing switches
F Using the right hand, turn the
padlockable button and
maintain it there.
F Insert the lever.
F Make the rod slide upwards
then grip the lever by both of its
extremities.
F Lower the lever towards the left.
F The earthing switches are now
open.
F Remove the lever.
13.2 Closing the load break switch
F Using the left hand, turn the
padlockable button and
maintain it there.
F Insert the lever.
F Make the rod slide upwards
then grip the lever by both of its
extremities.
F Lower the lever towards the
right.
F The switch is now closed.
F Remove the lever.
