14 Operating the PGC Functional Unit
14.1 Opening the downstream earthing switch.
F Using the right hand, turn the
padlockable button and
maintain it there.
F Insert the lever.
F Make the rod slide upwards
then grip the lever by both of its
extremities.
F Lower the lever towards the left.
F The earthing switch is now
open.
The door panel is now.
locked.
14.2 Opening the upstream earthing switch.
F Using the right hand, turn the
padlockable button and
maintain it there.
F Insert the lever.
F Make the rod slide upwards
then grip the lever by both of its
extremities.
F Lower the lever towards the left.
F The earthing switch is now
open.
F Remove the lever.
