69
Operation
Never shift the transmission while your ATV is in motion. Should your ATV be on a
surface that is not level, engage the parking brake (brake lever lock) before shifting
into another gear or into reverse.
CAUTION
Always shift the transmission into LOW range when operating on wet or uneven
terrain, when towing or pushing heavy loads, or when using a plow. Failure to follow
this caution may result in premature V-belt failure or other damage to the drive system.
CAUTION
WARNING
Do not start the engine or operate your ATV with the clutch shield removed.
Severe injury could result.
Parking
Parking requires following the previous rules of braking; then:
1. When the ATV comes to a complete stop, shift ATV into the “P” (Park) position.
NOTE: Always try to park your ATV on level ground. If you have to park on a
hill, shift the ATVs transmission into the “P” (Park) position.
2. Stop the engine using the emergency stop switch located on the handlebar.
3. Turn the ignition switch to the “OFF” position.
4. Engage the parking brake.
Dismounting the ATV
1. Double-check that the parking brake (lever lock) is engaged.
2. Swing your right leg over to the left side of the seat.
3. Step to the ground on the left side of the ATV.
Transmission Ranges
This ATV is equipped with an automatic, dual-range transmission with reverse
capability. To shift your ATV into the dierent drive ranges, follow the below steps.
To properly change transmission range:
1. Apply brake.
2. Move shift lever to the desired range.
3. Release brake.
NOTE: The HIGH range is for normal riding conditions with light loads. The
LOW range is for carrying heavy loads, slow speeds or trailer towing. LOW
range position provides slower speed and greater torque to the wheels.
