ASCOM i63 User Manual

PRELIMINARY
Maintenance
USER MANUAL
Ascom i63 VoWiFi Handset
Figure 15. Replace the Battery
14.2 Easy Replacement of Handset
Easy replacement can be used if a handset needs to be replaced due to, for example, a broken display. The
easy replacement procedure is done via the handset display.
Easy replacement is not supported when using DP1 Desktop Programmer.
The following settings are replaced during easy replacement:
• User parameters (including User ID)
• Contacts
• The extension number is assigned to the new handset.
The following settings are not replaced during the easy replacement:
• Call list
• Messages
• Bluetooth pairing list
• Licenses.
87 TD 93289EN / / Ver.

ASCOM i63 Specifications

General

Display Type	TFT, 256K colors
Battery	Removable Li-Ion 800 mAh battery
Internal Memory	64 MB
Technology	GSM
Display Size	2.2 inches
Resolution	240 x 320 pixels
Network	GSM 900 / 1800 / 1900
External Memory	microSD
Bluetooth	Yes
USB	Yes
