Copyright © 2016 ASIX Electronics Corporation. All rights reserved.
AX99100
PCIe to Multi I/O Controller
SPI Master Controller (SPI) 2.6
The AX99100 contain the High Speed Serial Peripheral Interface (SPI) Master Controller provides a full-duplex,
synchronous serial communication interface (4 wires) to flexibly work with numerous SPI peripheral devices. The
High Speed SPI Controller consists of a High Speed SPI master controller with 3 slave select pins, SS[2:0], to connect
up to 7 SPI devices.
This High Speed SPI master controller supports 4 types of interface timing mode, namely, Mode 0, Mode 1, Mode 2,
and Mode 3 to allow working with most SPI devices available. It supports MSB/LSB first data transfer. The SCLK
SPI clock is programmable by software and can run up to 42MHz. The AX99100 also provides many programmable
registers can be used to adjust the bus timing to fit the variety Slave timing requirements. Please reference the section
4.5.4.
The AX99100 SPI master supports four kinds of access types below.
Non-Burst-Type Transfer: Supports up to 8 bytes registers can be read and written by Software with none DMA
access.
Burst-Type Transfer: Supports TX/RX DMA transfer. Upon configured by software and one DMA length up to
64K bytes, SPI RX DMA supports moving data from SPI bus through SPI RX FIFO into PCIe BUS; SPI TX DMA
supports moving data from PCIe BUS through SPI TX FIFO to SPI bus.
Burst-Type with OP-code Transfer: supports up to 8 bytes pre-programmable OP code automatic insertion in each
Burst-Type Transfer with successive chip select assertion, to reduce CPU/software loading.
Fragmentation: supports to fragment large data block into several smaller transfers on SPI bus with programmable
length for each small transfer fragment, to reduce CPU/software loading.
