AX99100
PCIe to Multi I/O Controller
Copyright © 2016 ASIX Electronics Corporation. All rights reserved.
6 Ordering Information
68-pin QFN lead Free package, commercial temperature range: 0 to 70°C.
68-pin QFN lead Free package, Industrial temperature range: -40 to 85°C.
7 Revision History
1. Added some descriptions for offset 0x55 bit2~6 in Section 3.3.1.
2. Changed offset 0x20 and 0x2A, Active 0/1 to Low/High in Section 3.3.2.
3. Added offset 0x5A~0x56 as Reserved fields in Section 3.3.2.
4. Added some descriptions for Local Address Space 0/1 Timing Setting, Local
Address Space 0/1 Address Setting in Section 3.3.2.
1. Changed offset 0x14 from 0xFF to 0xFD, offset 0x58 from 1 to 00 and offset
0x5B from 0x9F to 0xA2 in Table 3-7.
2. Added offset 0x53 ~ 0x54 and 0x56 in Table 3-4, Table 3-5 and section 3.3.1.
3. Added more descriptions in section 3.3 and 3.3.4.
1. Changed the offset 0x56 naming from “PCIe Function Enable” to “Global
Setting” in Table 3-4 and Table 3-5.
1. Changed the offset 0x58 from 0x01 to 0x00 for LB mode in Table 3-6.
2. Changed bit11:10 to “Reserved” for offset 0x21~0x20 and 0x2B~0x2A in
section 3.3.2.
