ASIX AX99100 User Manual

54
AX99100
PCIe to Multi I/O Controller
Copyright © 2016 ASIX Electronics Corporation. All rights reserved.
Power Consumption 4.3
Interface
Configuration
Loading
Condition
VCCIO
VCCK
VCC12A_TX
VCC12A_D
VCC12A_AUX
Unit
4S
L0
Idle
2.5
36.7
12
19.2
17.1
mA
Full load
4 Serial Ports with 25Mhz Baud Rate
5.5
53.3
12
19.2
17.1
mA
L1
0
30.8
2.8
16.2
12.5
mA
L2
1.2
0.1
3.6
0.7
8.3
mA
ASPM L0s
Idle
3.1
35.6
13.2
17.7
14.8
mA
Full load
4 Serial Ports with 25Mhz Baud Rate
4.6
51.8
13.2
17.7
16.4
mA
LB
L0
Idle
5.9
35.9
12.6
18.8
14.6
mA
Full load
Synchronous 16-bit Multiplexed Bus
with 62.5MHz Local Bus clock
24.7
38.1
12.6
18.8
14.6
mA
L1
5.5
34.4
10.7
17.0
12.2
mA
L2
1.0
0.0
3.79
0.5
8.6
mA
ASPM L0s
Idle
4.9
30.0
13.4
16.9
15.7
mA
Full load
24.0
36.7
13.4
16.9
15.7
mA
Note: The measurement is for the operation at Typical Condition and used ASIX 4S and Local Bus test board.
Symbol
Description
Condition
Min
Typ
Max
Unit
ΘJC
Thermal resistance of junction to case
-
11.9
-
°C/W
ΘJA
Thermal resistance of junction to ambient
Still air
-
28.3
-
°C/W

JT
Junction to Top of the Package Characterization Parameter
-
0.30
-
°C/W
